The Splinter Galaxy (NGC 5907)

clic for 36% size 1380 x 1428 (375 kB)

Clic here for 60% size 2300x2380 (735 kB)


About this Image

NGC 5907 is a spiral galaxy located approximately 50 million light years from Earth. It is a member of the NGC 5866 Group including beside NGC 5866 also NGC 5879 in the constellation Draco.

NGC 5907 has long been considered a prototypical example of a warped spiral in relative isolation. Then in 2006, an international team of astronomers announced the presence of an extended tidal stream surrounding the galaxy that suggests the gravitational perturbations induced by the stream progenitor may also be the cause for the warp, see the publication here.

The tidal loops are not visible in this image taken from a light polluted site.Yet many faint background galaxies in a filamentary structure can be found in this wider field image measuring 30 arc min in both axes.

North is at right.

Find a close-up on the galaxy in 35/80% size below.

clic for 80% size 1693 x 1197 (265 kB)


Technical Details


16" cassegrain in corrected secondary focus at f/10

Mount ASA DDM-85XL
Camera SBIG STX16803 at -30C, STX filter wheel
Filters Baader 65x65mm LRGB
Date June 2011
Location Wildon/Austria
Sky Conditions mag 5.5 sky, raw FWHM 1.6-2.2", temperature 15-22 C
Exposure L:R:G:B = 600:100:100:100 minutes (20-minute sub-exposures)
Programs used Autoslew
Maxim DL 5
Photoshop CS5
