Lunar Eclipse March 03, 2007

clic for 36% size 1135 x 853 (150 kB)

clic here for 60% size 1891 x 1421 (359 kB)

clic here for 100% size 3152 x 2368 (828 kB)

clic for a 270 frame video showing the full eclipse sequence (4300 kB)



About this Image

A total Eclipse, the only one visible from Europe this year is a spectacular view. The Moon entered the Umbra at 21h30 UT and reached the maximum occultation at 23h30 UT.
At that time the photo above has been taken.

To show the view as seen from the eyepiece of a telescope a combination of 10 sec and 60 sec exposures were combined. A lot of background stars and some galaxies are visible. At 10h the mag 15.6 spiral galaxy PGC 33058 can be seen in the 100% image.

Above you find a link to a video sequence showing the complete eclipse in 1 minute intervals over 4 hours.
The video sequence has been taken with the TEC-140 incl. flattener and the Canon 10D, downsized to 50% and cropped.




Technical Details

Optics

16" cassegrain in primary focus at f/3

Mount MK-100 GEM
Camera SBIG STL-11000M at -25C, internal filter wheel
Filters Astronomik LRGB
Date Mar 03, 2007.
Location Wildon/Austria
Sky Conditions very unstable seeing, high transparency, raw FWHM 3.5-5", temperature 5 C
Exposure L:R:G:B = 5:5:5:5 sec for Moon (5 sec subexposures)
L:R:G:B = 120:60:60:60 for background (60 sec subexposures)
Processing Image aquisition and calibration in Maxim, layering of exposures, color balance, unsharp mask in Photoshop;
north is up;
